UNIVERSAL COMPATIBILTY INCLUDING THE MIOST ADVANCED CHARGING STANDARD IN THE WORLD - PPS SUPER FAST CHARGING
The most advanced Programmable Power Supply PD 3.0 charging technology backed up by the full backwards compatibility of Quick Charge 4+. The Smart IQ PPS charger plug communicates every few seconds with your devices for constant real time dynamic stepwise changes in current and voltages. This ensures the charging is always at the fastest the device can handle while keeping heat conversion loss to the minimum. Not only does this save electricity, but it also ensures much greater safety and less heat; increasing the battery cell and associated components' lifespan and electrical integrity.

PREMIUM MATERIALS & COMPONENTS
Gallium Nitride is an expensive rare earth material but provides greater efficiency, much higher power density, lower heat output and greater safety. The latest GaN III standard is the most advanced and efficient of its type. Thermal resistant materials & superior components ensure peace of mind & long-term reliability.

SAFE STABLE CLEAN POWER DELIVERY
Innovative UK design paired with the highly efficient chipset provides your devices with the cleanest, safest power output. Outstanding noise suppression and very low ripple. Clean Power delivery protects your devices from long term electrical degradation ensuring greater reliability & longevity.

TITANIUM STANDARD 95%+ EFFICIENCY
Advanced eco-efficient circuitry protects the environment, lower energy bill, limit wasted heat output & ensures greater durability. UK designed multi-point fail safe system ensures complete protection from short circuit, over-current, over-voltage & over-heating.

UK DESIGN. UK TECH SUPPORT
Support British design with full CE, FCC, RoHS UKCA Certification. UK Standard Plug. Free UK online tech support.

Specifications

Model
CHARGER-MAIN-GAN-USBC-100W-EZW

Port
1 x Type A Quick Charge 3.0
2 x Type C PD 3.0 Power Delivery Quick Charge 4+ (Cable not included)

Dimension
68mm x 66mm x 32mm (Base unit not including plug)

Product Weight
250g

Circuitry
Smart IQ Chipset

Plug Standard
UK

Output Power
100W Max

Input
100-240V~50/60Hz 2A

Connections
USB-C1/C2:5V -3A,9V- 3A,12V- 3A,15V 3A,20V- 5A
USB-A:5/9/12/20V- 3A
USB-C1+USB-C2:65W(5V- 3A,9V-3A,12V-3A,15V-3A,20V-3.25A)+35W(5V- 3A,9V- 3A,12V- 2.5A,15V- 2.33A,20V- 1.75A)
USB-C1+USB-A:65W(5V- 3A,9V- 3A,12V- 3A,15V- 3A,20V- 3.25A)+30W(5V- 3A,9V- 3A,12V- 2.5A,20V- 1.5A)
USB-C2+USB-A:24W(5V- 4.8A)
USB-C1+(USB-C2+USB-A):65W(5V- 3A,9V- 3A,12V- 3A,15V- 3A,20V- 3.25A)+24W(5V- 4.8A)
