| Connection A | HDMI (M) |
| Connection B | HDMI (M) |
| Length | 3m |
| Colour | Black |
| Connection A | HDMI (M) |
| Connection B | HDMI (M) |
| Length | 3m |
| Colour | Black |
| FEATURES | |
|---|---|
| Certification | RoHS, REACH, UL, ATC |
| Plug and Play | Yes |
| Cable length | 3 m |
| Cable type | Round cable |
| Colour depth | 8 bit |
| Data transfer rate | 18 Gbit/s |
| Maximum resolution | 4096 x 2160 pixels |
| Product colour | Black, Grey |
| Connector material | Gold |
| Supported graphics resolutions | 4096 x 2160 |
| Supported video modes | 2160p |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | HDMI Type A (Standard) |
| Connector contacts plating | Gold |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| AWG wire size | 30 |
| Cable material | Copper |
| HDMI Ethernet channel | Yes |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Cable jacket material | Polyvinyl chloride (PVC) |
| Quantity per pack | 1 pc(s) |
| Shield material | Copper |
| Bending radius (min) | 4.8 cm |
| Contact material | Phosphor copper |
| Colour sampling | 4:4:4 |
| Nominal attenuation | 300kHz-825MHz <5dB 825MHz-2.475GHz <5dB 2.475GHz-4.125GHz <12dB 4.125GHz-5.1GHz <20dB |
| Connector housing material | Polyvinyl chloride (PVC) | LOGISTICS DATA |
| Harmonized System (HS) code | 84733080 | OPERATIONAL CONDITIONS |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating temperature (T-T) | -10 - 80 °C | WEIGHT & DIMENSIONS |
| Package type | Polybag |
| Cable diameter | 6 mm |
| Connector 1 dimensions (WxDxH) | 20 x 34.2 x 10.9 mm |
| Connector 2 dimensions (WxDxH) | 20 x 34.2 x 10.9 mm |
