| Type | Mesh |
| Speed | AX2400 |
| Indoor or Outdoor | Indoor/Outdoor |
| POE Capability | 48v |
| Pack Size | Single |
| Type | Mesh |
| Speed | AX2400 |
| Indoor or Outdoor | Indoor/Outdoor |
| POE Capability | 48v |
| Pack Size | Single |
| ANTENNA | |
|---|---|
| Antenna type | Internal |
| Antenna gain level (max) | 8 dBi |
| Antenna direction type | Omni-directional | DESIGN |
| LED indicators | Yes |
| Product colour | White |
| Reset button | Yes |
| Housing material | Polycarbonate (PC) |
| International Protection (IP) code | IPX6 |
| Placement | Pole, Wall |
| Recommended usage | Indoor/outdoor | ENERGY MANAGEMENT |
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 42.5 - 57 V |
| Power consumption (max) | 9 W | FEATURES |
| Maximum data transfer rate | 2400 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| VLAN support | Yes |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Maximum data transfer rate (2.4 GHz) | 573.5 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
| 6 GHz | No | LOGISTICS DATA |
| Quantity per pack | 1 pc(s) | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -30 - 60 °C | PACKAGING CONTENT |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Number of products included | 1 pc(s) |
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
| PoE adapter included | Yes | PACKAGING DATA |
| AC adapter included | Yes |
| Quick start guide | Yes |
| Number of products included | 1 pc(s) |
| Mounting kit | Yes |
| PoE adapter included | Yes | PORTS & INTERFACES |
| Ethernet LAN (RJ-45) ports | 2 | SECURITY |
| Security algorithms | WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 | SUSTAINABILITY |
| Sustainability compliance | Yes | WEIGHT & DIMENSIONS |
| Weight | 819 g |
| Height | 343.2 mm |
| Width | 181.2 mm |
| Depth | 60.2 mm |
