UniFi Switch Pro 48 is a fully managed Layer 3 switch with (48) Gigabit Ethernet ports. (4) 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability.

The UniFi Switch Pro 48 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Switch Pro 48 is an ideal aggregation and access layer switch for any UniFi solution – it combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.

Features
(48) Gigabit RJ45 ports
(4) 10G SFP+ ports
Layer 2 and Layer 3 features
UniFi SmartPower RPS DC input
Near-silent cooling
1.3" touchscreen display
Managed by UniFi Network Controller

Warranty:

Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.

CERTIFICATION
Certification	CE, FCC, IC ETSI300-019-1.4
DATA TRANSMISSION
Switching capacity	176 Gbit/s
Forwarding rate	130.944 Mpps
DESIGN
Certification	CE, FCC, IC ETSI300-019-1.4
Rack mounting	Yes
Form factor	1U
LED indicators	Activity, Link, Speed
Backlight display	Yes
Product colour	Silver
ENERGY MANAGEMENT
Input current	5.22 A
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
DC input voltage	11.5 V
Power consumption (max)	60 W
Power supply included	Yes
LOGISTICS DATA
Harmonized System (HS) code	85176990
MANAGEMENT FEATURES
Switch layer	L2/L3
Switch type	Managed
NETWORKING
Networking standards	IEEE 802.1x
Flow control support	Yes
Port mirroring	Yes
Link aggregation	Yes
Broadcast storm control	Yes
Spanning tree protocol	Yes
VLAN support	Yes
10G support	Yes
OPERATIONAL CONDITIONS
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-5 - 45 °C
PACKAGING CONTENT
User guide	Yes
PACKAGING DATA
User guide	Yes
PERFORMANCE
Harmonized System (HS) code	85176990
PORTS & INTERFACES
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
SFP+ module slots quantity	4
POWER OVER ETHERNET (POE)
Power over Ethernet (PoE)	No
SECURITY
Authentication type	IEEE 802.1x, RADIUS
WEIGHT & DIMENSIONS
Weight	4 kg
Height	43.7 mm
Width	442.4 mm
Depth	285.4 mm
