| Speed | 2.5 GbE |
| Ports | 5 |
| POE Capability | No |
| Managed or Unmanaged | Managed |
| Rack Mountable | No |
| Speed | 2.5 GbE |
| Ports | 5 |
| POE Capability | No |
| Managed or Unmanaged | Managed |
| Rack Mountable | No |
| CERTIFICATION | |
|---|---|
| Certification | CE, FCC, IC |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) | DATA TRANSMISSION |
| Switching capacity | 25 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 18.6 Mpps |
| Throughput | 12.5 Gbit/s | DESIGN |
| Certification | CE, FCC, IC |
| Form factor | Desktop |
| LED indicators | Activity, Power, Progress |
| Product colour | White |
| Reset button | Yes |
| Housing material | Polycarbonate (PC) | ENERGY MANAGEMENT |
| Power source | AC/DC/PoE |
| Input current | 1 A |
| DC input voltage | 5 V |
| Power consumption (max) | 5 W |
| Power supply included | Yes |
| Power plug type | Type A | MANAGEMENT FEATURES |
| Switch type | Managed | MULTICAST FEATURES |
| Multicast support | Yes | NETWORKING |
| Flow control support | Yes |
| Port mirroring | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| 10G support | No |
| Copper ethernet cabling technology | 2.5GBASE-T | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -20 - 45 °C | OTHER FEATURES |
| Networking features | STP / RSTP with priorities and port-level disable, Egress rate limit | PACKAGING DATA |
| AC adapter included | Yes | PERFORMANCE |
| Minimum system requirements | UniFi Network Version 8.4.62 and later | PORTS & INTERFACES |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Power connector | USB |
| USB Type-C ports quantity | 1 |
| 2.5G Ethernet (copper) ports quantity | 5 | POWER OVER ETHERNET (POE) |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 57 V |
| Power over Ethernet (PoE) power per port | 6.4 W | TECHNICAL DETAILS |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) | WEIGHT & DIMENSIONS |
| Weight | 206 g |
| Height | 21.2 mm |
| Width | 117.1 mm |
| Depth | 90 mm |
