Managed mobile WiFi router that brings plug-and-play connectivity to any environment. Bring your own nano-SIM for LTE data.

Dimensions
220.6 x 89.8 x 28.8 mm (8.7 x 3.5 x 1.1")

Weight
Without mount: 257 g (9.1 oz)
With mount: 303 g (10.7 oz)

Enclosure Material
Polycarbonate

Mount Material
Wall mount: polycarbonate
DIN rail mount: steel

Processor
74 Kc MIPS processor at 775 MHz

Memory Information
128 MB DDR2

Management Interface
Ethernet
WiFi

Networking Interface
(2) GbE RJ45 ports
LTE Category 4 radio
WiFi

POE Interface
(1) PoE input
(1) PoE output (Max. 10W)

SIM
Nano SIM

LTE Bands
B1, B3, B7, B8, 20, B28

3G Bands
B1, B8

LTE Throughput Speed
Download 150 Mbps / Upload 50 Mbps

WiFi Standards
802.11 b/g/n, WiFi 2.4G, 20/40 MHz

GPS
Yes

Antennas
(1) External LTE antenna (main + aux) with TS9 male connectors
(1) Internal WiFi 2.4 GHz antenna
(1) Internal GPS antenna

Power Supply
UniFi PoE switch (48—54V DC, 0.625A)
USB Type-C (5V DC, 3A)
4-pin ATX DC power socket (9V DC, 1A)

Max. Power Consumption
9W

LCM Display
1.3" screen

Button
Factory Reset

Mounting
DIN rail/wall (Included)

Certifications
CE, UKCA, GCF

Warranty:

Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.

ANTENNA
Antenna type	Internal & external
Antenna connector type	TS-9
Antennas quantity	3
DESIGN
Display diagonal	3.3 cm (1.3")
Product colour	White
Mounting	DIN-rail/Wall mounting
Device type	Cellular network router
Reset button	Yes
Housing material	Polycarbonate (PC)
Built-in display	Yes
Display type	LCM
ETHERNET LAN FEATURES
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
GPS PERFORMANCE
GPS (satellite)	Yes
MOBILE NETWORK
Data network	3G, 4G
SIM card type	NanoSIM
4G standard	LTE
Data transfer rate (LTE) (download)	150 Mbit/s
Data transfer rate (LTE) (upload)	50 Mbit/s
OPERATIONAL CONDITIONS
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-20 - 45 °C
PACKAGING DATA
User guide	Yes
PERFORMANCE
Certification	CE, UKCA, GCF
Antenna type	Internal & external
Antenna connector type	TS-9
GPS (satellite)	Yes
Antennas quantity	3
Built-in processor	Yes
RAM capacity	0.128 GB
Processor frequency	0.775 GHz
RAM type	DDR2
PORTS & INTERFACES
Ethernet LAN (RJ-45) ports	2
Compatible memory cards	TS-9
USB port	Yes
USB port type	USB Type-C
POWER
Output voltage	48 - 54 V
Power source type	DC, PoE, USB
TECHNICAL DETAILS
Compatible memory cards	TS-9
WEIGHT & DIMENSIONS
Weight	303 g
Height	220.6 mm
Width	89.8 mm
Depth	28.8 mm
WIRELESS LAN FEATURES
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi	Yes
WLAN data transfer rates supported	1,2,5.5,6,9,11,12,18,24,36,48,54,150 Mbit/s
Wi-Fi frequency	2.4 GHz
