Device Protection
PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.

Output
24VDC @ 1.0A

Warranty:

Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.

ENERGY MANAGEMENT
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Input current	0.4 - 0.6 A
Output current	1 A
Power over Ethernet (PoE) voltage	24 V
FEATURES
Product colour	Black
Surge protection	Yes
LOGISTICS DATA
Harmonized System (HS) code	85044095
NETWORKING
Power over Ethernet (PoE)	Yes
Ethernet LAN data rates	10,100 Mbit/s
Ethernet interface type	Fast Ethernet
OPERATIONAL CONDITIONS
Operating relative humidity (H-H)	35 - 95%
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	32 - 104 °F
PORTS & INTERFACES
Ethernet LAN (RJ-45) ports	2
RJ-45 input ports	1
RJ-45 output ports	1
TECHNICAL DETAILS
Harmonized System (HS) code	85044095
WEIGHT & DIMENSIONS
Dimensions (WxDxH)	88 x 57 x 33 mm
Weight	135 g
Height	33 mm
Width	57 mm
Depth	88 mm
