Device Protection
PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.

Convenient Wall-Mounting
The 24V, 0.5A models, POE-24-12W and POE-24-12W-G, are wall-mountable using the optional wall-mount brackets.

Seamless airGateway Compatibility
The 15V, 0.8A and 24V, 0.5A models, POE-15-12W, POE-24-12W and POE-24-12W-G, work with the airGateway to bridge airMAX® connections to Wi-Fi at customer locations.

Output Voltage
24VDC @ 0.5A

Gigabit LAN Port
No

Warranty:

Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.

ENERGY MANAGEMENT
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Input current	0.2 - 0.3 A
Output current	0.5 A
Power over Ethernet (PoE) voltage	24 V
FEATURES
Product colour	Black
Surge protection	Y
LOGISTICS DATA
Harmonized System (HS) code	85044095
NETWORKING
Power over Ethernet (PoE)	Y
OPERATIONAL CONDITIONS
Operating relative humidity (H-H)	35 - 95%
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	32 - 104 °F
PORTS & INTERFACES
Ethernet LAN (RJ-45) ports	2
RJ-45 input ports	1
RJ-45 output ports	1
TECHNICAL DETAILS
Harmonized System (HS) code	85044095
WEIGHT & DIMENSIONS
Weight	92 g
Height	29 mm
Width	44 mm
Depth	87 mm
