Key Features
8 10/100/1000Mbps RJ45 ports
Supports MAC address auto-learning and auto-aging and auto MDI/MDIX
Standard 13-inch rackmount steel case (rackmount bracket for 19" mounting is included)
802.1p/DSCP QoS enable smooth latency-sensitive traffic
HARDWARE FEATURES
Standards and Protocols
IEEE 802.3i
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3x
IEEE 802.1p
Interface
8 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity
Fanless
Power Supply
100-240VAC, 50/60Hz
Power Consumption
Maximum: 4.1W
Dimensions ( W x D x H )
11.6 x 7.1 x 1.7 in.
(294 x 180 x 44 mm)
Mounting
13" or 19" Rack Mountable
Max Power Consumption
4.3W
Max Heat Dissipation
14.67BTU/h
PERFORMANCE
Switching Capacity
16Gbps
Packet Forwarding Rate
11.9Mpps
MAC Address Table
4K
Jumbo Frame
16KB
Transfer Method
Store-and-Forward
SOFTWARE FEATURES
Advanced Features
MAC address auto-learning and auto-aging
IEEE802.3x Flow control
802.1p/DSCP QoS
OTHERS
Certification
FCC, RoHS
Package Contents
8-Port Gigabit Desktop Switch
Power Cord
Installation Guide
Rackmount kit
Rubber Feet
Environment
Operating Temperature: 0 - 40
Storage Temperature: -40 - 70
Operating Humidity: 10% - 90% non-condensing;
Storage Humidity: 5% - 90% non-condensing
Warranty:
Manufacturer Lifetime Warranty
DATA TRANSMISSION
|
MAC address table |
4000 entries |
Switching capacity |
16 Gbit/s |
Jumbo frames support |
Y |
Store-and-forward |
Y |
Jumbo frames |
16000 |
DESIGN
|
Rack mounting |
Y |
LED indicators |
Y |
Product colour |
Black |
ENERGY MANAGEMENT
|
Power consumption (typical) |
4.3 W |
AC input frequency |
50 - 60 Hz |
AC input voltage |
100 - 240 V |
Power supply included |
Y |
MANAGEMENT FEATURES
|
Switch type |
Unmanaged |
NETWORKING
|
Full duplex |
Y |
Networking standards |
IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Flow control support |
Y |
Auto MDI/MDI-X |
Y |
10G support |
N |
Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
OPERATIONAL CONDITIONS
|
Operating relative humidity (H-H) |
10 - 90% |
Storage temperature (T-T) |
-40 - 70 °C |
Operating temperature (T-T) |
0 - 40 °C |
Storage relative humidity (H-H) |
5 - 90% |
Heat dissipation |
14.67 BTU/h |
PACKAGING DATA
|
Cables included |
AC |
Quick start guide |
Y |
Package type |
Box |
PORTS & INTERFACES
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity |
8 |
POWER OVER ETHERNET (POE)
|
Power over Ethernet (PoE) |
N |
PROTOCOLS
|
Supported network protocols |
CSMA/CD, TCP/IP |
WEIGHT & DIMENSIONS
|
Height |
44 mm |
Width |
294 mm |
Depth |
180 mm |
