| CERTIFICATION | |
|---|---|
| Certification | CE, FCC, RoHS | DATA TRANSMISSION |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Jumbo frames support | Yes |
| Number of queues | 8 |
| Forwarding rate | 14.9 Mpps |
| Packet buffer memory | 4.1 MB |
| Jumbo frames | 9000 | DESIGN |
| Certification | CE, FCC, RoHS |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Number of fans | 1 fan(s) | ENERGY MANAGEMENT |
| Power source | AC |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 173.9 W |
| Power supply included | Yes | LOGISTICS DATA |
| Harmonized System (HS) code | 85176990 | MANAGEMENT FEATURES |
| MIB support | RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1213, RFC2233, RFC1643, RFC1493 |
| Switch layer | L2/L2+ |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| ARP inspection | Yes |
| Configuring Location Settings (CLI) | Yes |
| Cloud-managed | Yes | MULTICAST FEATURES |
| Multicast support | Yes | NETWORKING |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Flow control support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Number of VLANs | 4000 |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Virtual LAN features | MAC address-based VLAN, Multicast VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 594.46 BTU/h | OPTICAL FIBER |
| Fiber ethernet cabling technology | 100BASE-FX, 1000BASE-X | PACKAGING DATA |
| Package weight | 2.12 kg |
| Package depth | 400 mm |
| Package height | 80 mm |
| Package width | 250 mm | PERFORMANCE |
| Harmonized System (HS) code | 85176990 | PORTS & INTERFACES |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| SFP module slots quantity | 2 | POWER OVER ETHERNET (POE) |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 150 W | PROTOCOLS |
| Management protocols | SNMPv1/v2c/v3, SNTP | SECURITY |
| Security algorithms | EAP-LEAP, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS |
| Access Control List (ACL) | Yes |
| SSH/SSL support | Yes |
| IGMP snooping | Yes |
| BPDU filtering/protection | Yes |
| IP-MAC-Port binding | Yes |
| Queue scheduling algorithms | SP, Weighted Round Robin (WRR) |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping | WEIGHT & DIMENSIONS |
| Height | 44 mm |
| Width | 294 mm |
| Depth | 180 mm |
