Blazing-Fast WiFi 6 Speeds
Simultaneous 574 Mbps on 2.4 GHz and 4804 Mbps on 5 GHz totals 5378 Mbps WiFi speeds.
High-Efficiency WiFi 6
More connected devices can enjoy faster speeds.
Centralized Cloud Management
Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app.
160 MHz Channel
Double the data at peak transmission times on a single stream with HE160.
Seamless Roaming
Video streams and voice calls are unaffected as users move between locations.
Omada Mesh
Enables wireless connectivity between access points for extended range and flexible deployment.
PoE+ Powered
Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations.
Specifications
HARDWARE FEATURES
Interface:
1× 2.5 Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Button:
Reset
Power Supply:
• 802.3at PoE
• 12 V / 1.5 A DC
Power Consumption:
• EU: 18.1 W
• US: 19.8 W
Dimensions ( W x D x H ):
9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm)
Antenna Type:
Internal Omni
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 4× 5 dBi
Mounting:
Ceiling /Wall Mounting (Kits included)
WIRELESS FEATURES
Wireless Client Capacity:
250+**
Wireless Standards:
IEEE 802.11ax/ac/n/g/b/a
Frequency:
2.4 GHz and 5 GHz
Signal Rate:
• 5 GHz: Up to 4804 Mbps
• 2.4 GHz: Up to 574 Mbps
Wireless Functions:
• 1024-QAM
• 4x Longer OFDM Symbol
• OFDMA
• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• MU-MIMO
• HE160 (160 MHz Bandwidth)?
• Seamless Roaming §
• Omada Mesh§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
Wireless Security:
• Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power:
• CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz, , band1 & band2, EIRP)
<30 dBm(5 GHz, , band3, EIRP)
• FCC:
<25 dBm (2.4 GHz)
<28 dBm (5 GHz)
MANAGEMENT
Omada App:
Yes
Centralized Management:
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller
Cloud Access:
Yes (Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller)
Email Alerts:
Yes
LED ON/OFF Control:
Yes
Management MAC Access Control:
Yes
SNMP:
v1, v2c, v3
System Logging:
Local/Remote Syslog
SSH:
Yes
Web-based Management:
HTTP/HTTPS
L3 Management:
Yes
Multi-site Management:
Yes
Management VLAN:
Yes
Zero-Touch Provisioning:
Yes. Requiring the use of Omada Cloud-Based Controller.
OTHERS
Certification:
CE, FCC, RoHS
Package Contents:
• EAP670
• Power Adapter
• Ceiling/Wall Mounting Kits
• Installation Guide
System Requirements:
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Warranty:
3 Years Return to Base Warranty.
ANTENNA
|
Antenna type |
Internal |
Antenna gain level (max) |
5 dBi |
Antennas quantity |
6 |
Antenna direction type |
Omni-directional |
DESIGN
|
Certification |
CE, FCC, RoHS |
LED indicators |
Yes |
Product colour |
White |
Reset button |
Yes |
International Protection (IP) code |
IP67 |
Placement |
Ceiling, Wall |
ENERGY MANAGEMENT
|
Power over Ethernet (PoE) |
Yes |
Input current |
1.5 A |
FEATURES
|
Maximum data transfer rate |
5400 Mbit/s |
Frequency band |
2.4 - 5 GHz |
Number of users |
250 user(s) |
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Quality of Service (QoS) support |
Yes |
Rate limiting |
Yes |
Ethernet LAN data rates |
2500 Mbit/s |
Automatic channel selection |
Yes |
VLAN support |
No |
2.4 GHz |
Yes |
5 GHz |
Yes |
Wireless isolation |
Yes |
MIMO |
Yes |
Automatic channel scanning |
Yes |
Band steering |
Yes |
MIMO type |
Multi User MIMO |
Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
Maximum data transfer rate (5 GHz) |
4804 Mbit/s |
Transmitting power (FCC) |
<25 dBm (2.4 GHz); <28 dBm (5 GHz) |
Transmitting power (CE) |
<20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz, band1 & band2, EIRP); <30 dBm(5 GHz, band3, EIRP) |
BeamForming |
Yes |
6 GHz |
No |
LOGISTICS DATA
|
Harmonized System (HS) code |
85176990 |
MANAGEMENT FEATURES
|
Web-based management |
Yes |
Firmware upgradeable |
Yes |
PACKAGING CONTENT
|
Number of products included |
1 pc(s) |
PACKAGING DATA
|
Package weight |
1.32 kg |
Package depth |
304 mm |
Package height |
82 mm |
Package width |
302 mm |
Number of products included |
1 pc(s) |
SECURITY
|
Access Control List (ACL) |
Yes |
Number of SSID supported |
16 |
Remote Authentication Dial-In User Service (RADIUS) |
Yes |
Service Set Identifier (SSID) features |
Multiple SSIDs |
TECHNICAL DETAILS
|
Harmonized System (HS) code |
85176990 |
WEIGHT & DIMENSIONS
|
Height |
64 mm |
Width |
243 mm |
Depth |
243 mm |
