VigorAP 918R is a wireless access point designed for outdoor environments. It is ideal for providing wireless access to users and devices in any outdoor scenario, including restaurants, gardens, marinas, educational premises or, really, anywhere where outdoor access is needed.
The VigorAP 918R is a dual-band 802.11ac Wave 2 wireless access point and range extender that can be used a part of a DrayTek Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal and Wi-Fi dead zones. One access point acts as the controller (Mesh root) and in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling.
Initial setup of the VigorAP 918R is easy with the DrayTek Wireless app, whether it's creating a new Mesh network or being set up in AP and Range Extender modes, the Quick Start Wizard assists throughout.
Manage the VigorAP 918R centrally through the VigorACS central management platform, VigorConnect, Router AP Management, or simply on its own as a stand-alone access point.
The VigorAP 918R has the flexibility to be used how you need it, in any environment.
Warranty:
Manufacturers Warranty - For further details please visit the manufacturers website.
ANTENNA
|
Antenna type |
External |
Antenna gain level (max) |
5 dBi |
Antenna connector type |
RP-SMA |
Antennas quantity |
2 |
Antenna features |
Detachable antenna |
Antenna direction type |
Omni-directional |
CERTIFICATION
|
Compliance certificates |
RoHS |
DESIGN
|
Product colour |
White |
Reset button |
Yes |
International Protection (IP) code |
IP67 |
Placement |
Pole, Wall |
ENERGY MANAGEMENT
|
Power over Ethernet (PoE) |
Yes |
Power consumption (max) |
18 W |
FEATURES
|
Maximum data transfer rate |
866 Mbit/s |
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Channels quantity |
3 channels |
VLAN support |
Yes |
2.4 GHz |
Yes |
5 GHz |
Yes |
Wireless isolation |
Yes |
Wi-Fi Multimedia (WMM)/(WME) |
Yes |
MIMO |
Yes |
Fast roaming |
Yes |
MIMO type |
Multi User MIMO |
Maximum data transfer rate (2.4 GHz) |
400 Mbit/s |
Maximum data transfer rate (5 GHz) |
866 Mbit/s |
WLAN channel features |
WLAN channel management |
LOGISTICS DATA
|
Quantity per pack |
1 pc(s) |
Harmonized System (HS) code |
85176990 |
MANAGEMENT FEATURES
|
Web-based management |
Yes |
Firmware upgradeable |
Yes |
Syslog |
Yes |
Local AP management |
Telnet |
Command-line interface (CLI) |
Yes |
OPERATIONAL CONDITIONS
|
Operating relative humidity (H-H) |
5 - 95% |
Operating temperature (T-T) |
-40 - 70 °C |
Operating temperature range (T-T) |
Yes |
PACKAGING CONTENT
|
Cables included |
LAN (RJ-45) |
Quick start guide |
Yes |
Number of products included |
1 pc(s) |
Quantity per pack |
1 pc(s) |
PACKAGING DATA
|
Cables included |
LAN (RJ-45) |
Quick start guide |
Yes |
Number of products included |
1 pc(s) |
PORTS & INTERFACES
|
Ethernet LAN (RJ-45) ports |
1 |
Internal RJ-45 ports quantity |
1 |
PROTOCOLS
|
DHCP client |
Yes |
DHCP server |
Yes |
SECURITY
|
Security algorithms |
HTTPS, WEP, WPA, WPA2, WPS |
MAC address filtering |
Yes |
IP address filtering |
Yes |
Service Set Identifier (SSID) features |
Hidden SSID, Multiple SSIDs |
SUSTAINABILITY
|
Sustainability certificates |
RoHS |
TECHNICAL DETAILS
|
Harmonized System (HS) code |
85176990 |
Sustainability certificates |
RoHS |
Compliance certificates |
RoHS |
WEIGHT & DIMENSIONS
|
Weight |
1 kg |
Height |
460 mm |
Width |
161 mm |
Depth |
72 mm |
