ANTENNA
|
Detachable antenna(s) |
Yes |
Antenna design |
External |
DESIGN
|
LED indicators |
DMZ, LAN, LTE, Power, Status, USB, WAN, WLAN |
Wall mountable |
Yes |
Rack capacity |
1U |
On/off switch |
Yes |
FEATURES
|
Operating system installed |
DrayOS |
Firmware upgradeable |
Yes |
MANAGEMENT FEATURES
|
Wake-on-LAN ready |
Yes |
Quality of Service (QoS) support |
Yes |
Web-based management |
Yes |
Reset button |
Yes |
WPS push button |
Yes |
Wi-Fi Multimedia (WMM)/(WME) |
Yes |
MIMO |
Yes |
Web-based setup wizard |
Yes |
Bandwidth control |
Yes |
MU-MIMO technology |
Yes |
Intelligent Mesh technology |
Yes |
MOBILE NETWORKING
|
Short Message Service (SMS) |
Yes |
3G |
Yes |
Dual SIM support |
Yes |
4G |
Yes |
4G standard |
LTE-TDD & LTE-FDD |
3G standards |
WCDMA |
SIM card slot |
Yes |
5G |
Yes |
Mobile network generation |
5G |
5G standard |
NR, Sub6 NSA, Sub6 SA, Sub6 SA/NSA |
NETWORKING
|
Full duplex |
Yes |
Cabling technology |
10/100/1000Base-T(X) |
Ethernet LAN |
Yes |
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x |
VPN support |
IPsec IKEv1, IKEv2, IKEv2 EAP
IPsec-XAuth
DrayTek SSL VPN
OpenVPN
WireGuard
GRE over IPsec
PPTP
L2TP, L2TP over IPsec |
VPN tunnels quantity |
50 |
Flow control support |
Yes |
VPN throughput |
800 Mbit/s |
Port mirroring |
Yes |
Multicast support |
Yes |
Auto MDI/MDI-X |
Yes |
Number of VLANs |
8 |
Load balancing system |
Yes |
Port forwarding |
Yes |
Auto-sensing |
Yes |
Dynamic DNS (DDNS) |
Yes |
Ethernet LAN interface type |
Gigabit Ethernet |
Static route |
Yes |
SSID-based VLAN assignment |
Yes |
VPN Passthrough |
Yes |
Policy-based routing |
Yes |
Port triggering |
Yes |
VPN server |
Yes |
USB sharing |
Yes |
Number of guest networks (5 GHz) |
4 |
Number of guest networks (2.4 GHz) |
4 |
Wireless Distribution System (WDS) bridge |
Yes |
Wireless radio |
Yes |
Support Samba (storage) |
Yes |
Maximum Tx power (2.4 GHz) |
4.5 dBmW |
Maximum Tx power (5 GHz) |
5 dBmW |
OPERATIONAL CONDITIONS
|
Storage temperature (T-T) |
-25 - 70 °C |
Operating temperature (T-T) |
0 - 45 °C |
Storage relative humidity (H-H) |
10 - 90% |
Operating temperature (T-T) |
Yes |
OTHER FEATURES
|
Mobile network connection |
Yes |
PACKAGING CONTENT
|
AC adapter included |
Yes |
Cables included |
LAN (RJ-45) |
Quick start guide |
Yes |
Antenna included |
Yes |
PACKAGING DATA
|
AC adapter included |
Yes |
Cables included |
LAN (RJ-45) |
Quick start guide |
Yes |
Antenna included |
Yes |
PORTS & INTERFACES
|
USB 2.0 ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
5 |
USB port |
Yes |
POWER
|
Power consumption (typical) |
31.2 W |
Power source type |
AC |
PROTOCOLS
|
Routing protocols |
BGP |
DHCP client |
Yes |
DHCP server |
Yes |
Universal Plug and Play (UPnP) |
Yes |
SECURITY
|
Security algorithms |
3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, DES, SHA-1, SHA-256, SNMP, SNMPv2, SNMPv3, WPA2-PSK, WPA2-Personal, WPA2-RADIUS, WPA3, WPA3-Enterprise, WPA3-Personal |
Access Control List (ACL) |
Yes |
System event log |
Yes |
Parental control |
Yes |
DMZ support |
Yes |
IP address filtering |
Yes |
DoS attack prevention |
Yes |
Network address translation (NAT) |
Yes |
Firewall |
Yes |
URL filtering |
Yes |
Guest access |
Yes |
Filtering |
Yes |
Stateful Packet Inspection (SPI) |
Yes |
DDoS protection |
Yes |
Schedule access |
Yes |
Network address translation (NAT) throughput |
1800 Mbit/s |
TECHNICAL DETAILS
|
Vendor code |
V2927LAX-5G-K |
WAN CONNECTION
|
Dual SIM support |
Yes |
DSL WAN |
No |
Ethernet WAN |
Yes |
SIM card slot |
Yes |
3G/4G USB modem compatibility |
Yes |
WEIGHT & DIMENSIONS
|
Weight |
670 g |
Height |
44 mm |
Width |
241 mm |
Depth |
165 mm |
WIRELESS LAN FEATURES
|
Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (max) |
3000 Mbit/s |
Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
