| Screen Size (in) | 24 |
| Max Resolution | 1920x1080 |
| Refresh Rate | 60Hz |
| Response Time | <10ms |
| Display Port | Yes |
| HDMI | Yes |
| Curved Screen | No |
| Screen Size (in) | 24 |
| Max Resolution | 1920x1080 |
| Refresh Rate | 60Hz |
| Response Time | <10ms |
| Display Port | Yes |
| HDMI | Yes |
| Curved Screen | No |
| DESIGN | |
|---|---|
| Certification | cTUVus, FCC-B, ICES003, Energy Star 8.0, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, CCC, China RoHS, China Energy Label, CECP |
| Product colour | Black | DISPLAY |
| Pixel pitch | 0.2715 x 0.2715 mm |
| Contrast ratio (typical) | 3000:1 |
| Horizontal scan range | 24 - 82 kHz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Vertical scan range | 50 - 75 Hz |
| Display diagonal | 59.9 cm (23.6") |
| Contrast ratio (typical) | 5 - 90% |
| Display brightness | 200 cd/m² |
| Response time | 5 ms |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal (metric) | 60 cm |
| Touchscreen | Yes |
| Contrast ratio (dynamic) | 50000000:1 |
| Maximum refresh rate | 76 Hz |
| Touch technology | Multi-touch |
| Touchscreen technology | Projected capacitive system |
| Touchscreen type | Multi-user |
| Display technology | LCD |
| Number of simultaneous touchpoints | 10 |
| Native aspect ratio | 16:9 |
| HD type | Full HD |
| Panel type | VA |
| Screen shape | Flat | ENERGY MANAGEMENT |
| Power consumption (typical) | 25 W |
| Power supply type | AC |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100-240 V |
| Energy efficiency class (SDR) | E |
| Energy consumption (SDR) per 1000 hours | 15 kWh |
| European Product Registry for Energy Labelling (EPREL) code | 404623 | ERGONOMICS |
| Wall mountable | Yes |
| Tilt angle range | 20 - 53° |
| Panel mounting interface | 100 x 100 mm |
| Tilt adjustment | Yes |
| VESA mounting | Yes | LOGISTICS DATA |
| Harmonized System (HS) code | 85285210 | MULTIMEDIA |
| Built-in microphone | No |
| RMS rated power | 5 W |
| Built-in speaker(s) | Yes |
| Built-in camera | No |
| Number of speakers | 2 | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | OTHER FEATURES |
| Certification | cTUVus, FCC-B, ICES003, Energy Star 8.0, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, CCC, China RoHS, China Energy Label, CECP |
| Display viewable area (HxV) | 521.28 x 293.22 mm |
| Touchscreen | Yes |
| Touchscreen type | Multi-user |
| Mobile operating systems supported | Android |
| Number of simultaneous touchpoints | 10 |
| Compliance certificates | CE, REACH, RoHS | PACKAGING CONTENT |
| Cables included | AC, Audio (3.5mm), HDMI, USB | PACKAGING DATA |
| Package weight | 7.08 kg |
| Cables included | AC, Audio (3.5mm), HDMI, USB |
| Package depth | 140 mm |
| Package height | 435 mm |
| Package width | 643 mm | PERFORMANCE |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Other operating systems supported | Android |
| NVIDIA G-SYNC | No |
| AMD FreeSync | No | PORTS & INTERFACES |
| Headphone outputs | 1 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| HDMI | Yes |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Headphone out | Yes |
| Built-in USB hub | Yes |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 2 |
| Number of USB Type-B upstream ports quantity | 1 | SUSTAINABILITY |
| Sustainability certificates | ENERGY STAR, ErP |
| European Product Registry for Energy Labelling (EPREL) code | 404623 | TECHNICAL DETAILS |
| Compliance certificates | CE, REACH, RoHS | WEIGHT & DIMENSIONS |
| Width (with stand) | 573 mm |
| Height (with stand) | 353 mm |
| Depth (with stand) | 47 mm |
| Weight (with stand) | 5.51 kg |
