All-round colour clarity
See every inch clearly from any angle. The IPS panel preserves colour vividness and detail across the whole screen. Now, whole teams can work comfortably on the productivity-boosting wide display and view accurate tones and shades from 178° all around, with no colour washing.
More screen to focus on
The borderless design maximises concentration. Take in everything with just one glance on a display that looks almost gapless when used in a dual-monitor setup. With no distractions in your way, get through larger sections of your to-do list during screen time.
More ways to connect
A variety of inputs bring a convenient computing experience. With 2x HDMI 1.4 ports and a display port, enjoy the versatility of being able to plug multiple devices straight into your monitor.
Tailored to your use
Superior design for the ultimate in everyday versatility. The height-adjustable monitor swivels, tilts and pivots for you to see your work any way you want. The sleek and clean design adds a touch of style to your office interior and is VESA-compatible for easy installation.
Fresh eyes achieve more
Protected eyes stay focused through the whole shift. Advanced eye comfort technology reduces eye strain for heightened concentration and greater productivity. Flicker Free technology continuously removes tiring and irritating screen flicker, while Eye Saver Mode minimises blue light emissions.
Energy-saving display
Eco Saving Plus achieves power-consumption reductions of up to 10% while still maintaining picture quality. It adjusts the brightness of the screen's black sections while simultaneously adjusting the RGB gain values, so the screen looks just as bright as you remember.
Specifications
Display Type
LED-backlit LCD monitor / TFT active matrix
Energy Class
Class D
Energy Consumption per Year
18 kWh
Diagonal Size
22"
Adaptive-Sync Technology
AMD FreeSync
Built-in Devices
USB 2.0 hub
Panel Type
IPS
Aspect Ratio
16:9
Native Resolution
Full HD (1080p) 1920 x 1080 at 75 Hz
Brightness
250 cd/m?
Contrast Ratio
1000:1
Colour Support
16.7 million colours
Colour Gamut
72% (NTSC 1976)
Response Time
5 ms (grey-to-grey)
Horizontal Viewing Angle
178
Vertical Viewing Angle
178
Backlight Technology
LED backlight
Features
Game mode, Mega Dynamic Contrast Ratio, Flicker Free technology, Image Size, Eco Saving Plus, Eye Saver Mode, Off Timer Plus, Wide Viewing Angle, 3-sided bezeless
Colour
Black
Dimensions
(WxDxH)48.88 cm x 21 cm x 32.53 cm - with stand
Weight
3.5 kg
Connectivity
Interfaces
DisplayPort 1.2
2 x HDMI
Headphones
2 x USB 2.0
Mechanical
,b>Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Tilt Angle
-3/+25
Height Adjustment
100 mm
VESA Mounting Interface
100 x 100 mm
Cables Included
1 x HDMI cable
Power
Input Voltage
AC 120/230 V
Power Consumption (on model)
12 W
Power Consumption SDR (On mode)
12 kWh/1000h
Power Consumption (Typical)
12 Watt
Power Consumption Stand by
0.5 Watt
Power Consumption (Off Mode)
0.3 Watt
Operating Temperatures
Min Operating Temperature
10 degree C
Max Operating Temperature
40 degree C
Humidity Range Operating
10 - 80% (non-condensing)
Warranty:
2 Year Pick up & Return manufacturer's Warranty. Call 0330 SAMSUNG or +44 (0)1932 454358
DESIGN
|
Product colour |
Black |
Feet colour |
Black |
DISPLAY
|
Contrast ratio (typical) |
1000:1 |
Viewing angle, horizontal |
178° |
Viewing angle, vertical |
178° |
Aspect ratio |
16:9 |
Viewable size, horizontal |
47.6 cm |
Viewable size, vertical |
26.8 cm |
Display diagonal |
55.9 cm (22") |
Response time |
5 ms |
Colour depth |
8 bit |
Display resolution |
1920 x 1080 pixels |
Supported graphics resolutions |
1920 x 1080 (HD 1080) |
Supported video modes |
1080p |
Touchscreen |
No |
Maximum refresh rate |
75 Hz |
Native aspect ratio |
16:9 |
HD type |
Full HD |
Panel type |
IPS |
Screen shape |
Flat |
Display number of colours |
16.7 million colours |
Dynamic contrast ratio marketing name |
Mega Contrast |
NTSC coverage (typical) |
72% |
Display brightness (typical) |
250 cd/m² |
ENERGY MANAGEMENT
|
Power consumption (typical) |
12 W |
Power consumption (off) |
0.3 W |
Power consumption (standby) |
0.5 W |
AC input voltage |
100 - 240 V |
Energy efficiency scale |
A to G |
Energy efficiency class (SDR) |
D |
Energy consumption (SDR) per 1000 hours |
12 kWh |
European Product Registry for Energy Labelling (EPREL) code |
405781 |
ERGONOMICS
|
Height adjustment |
Yes |
Swivel angle range |
-45 - 45° |
Tilt angle range |
-3 - 25° |
Panel mounting interface |
100 x 100 mm |
Height adjustment |
10 cm |
Swivelling |
Yes |
Tilt adjustment |
Yes |
VESA mounting |
Yes |
Tiltable |
Y |
LOGISTICS DATA
|
Harmonized System (HS) code |
85285210 |
MULTIMEDIA
|
Built-in speaker(s) |
No |
Built-in camera |
No |
OPERATIONAL CONDITIONS
|
Operating relative humidity (H-H) |
10 - 80% |
Operating temperature (T-T) |
10 - 40 °C |
OTHER FEATURES
|
Compatible operating systems |
Windows10 |
Touchscreen |
No |
PACKAGING CONTENT
|
Cables included |
HDMI |
Stand included |
Yes |
PACKAGING DATA
|
Package weight |
4.7 kg |
Cables included |
HDMI |
Package depth |
358 mm |
Package height |
146 mm |
Package width |
553 mm |
Stand included |
Yes |
PERFORMANCE
|
Compatible operating systems |
Windows10 |
Game mode |
Yes |
NVIDIA G-SYNC |
No |
AMD FreeSync |
Yes |
Flicker-free technology |
Yes |
Low Blue Light technology |
Yes |
VESA Adaptive Sync support |
Yes |
PORTS & INTERFACES
|
Audio input |
No |
DVI port |
No |
HDMI ports quantity |
2 |
HDMI version |
1.4 |
HDMI |
Yes |
DisplayPorts quantity |
1 |
DisplayPort version |
1.2 |
Headphone out |
Yes |
Built-in USB hub |
Yes |
USB hub version |
2.0 |
USB Type-A downstream ports quantity |
2 |
SUSTAINABILITY
|
European Product Registry for Energy Labelling (EPREL) code |
405781 |
WEIGHT & DIMENSIONS
|
Width (with stand) |
488.8 mm |
Height (with stand) |
325.3 mm |
Depth (with stand) |
210 mm |
Weight (without stand) |
2.2 kg |
Height (without stand) |
294.4 mm |
Width (without stand) |
488.8 mm |
Depth (without stand) |
39.4 mm |
Weight (with stand) |
3.5 kg |
