The ThinkVision T23i-30 Monitor brings incredible display performance, comfort, convenience and functionality to your workstation. With a large 23" FHD screen this monitor packs an incredible view without taking up excessive desk space. Its IPS technology with 72% NTSC colour lets you view content with accurate colours and greyscale performance, even from off-centre angles, easing multi-person viewing during collaborations.
The extensive connectivity hub unleashes more possibilities by letting you connect to a limitless range of accessories and devices with its VGA, DP 1.2, HDMI 1.4 and Audio Out ports. The monitor is designed to keep you and the environment in mind. That is why it's made to meet the latest TCO 9.0 regulations, and comes encased in recyclable packaging. The ThinkVision T23i-30 Monitor is an innovation devised to assist you in making a wave of success without taking too much space.

Tech Specs

Screen Size
23"

Brightness
250 cd/? (typical)

Aspect Ratio
16:9

Contrast Ratio
1000:1

Backlight
WLED

Response Time
4/6/14(GTG)

Panel Type
In-Plane Switching

Viewing Angle
178° / 178°

Stand
Tilt Angle (-5° / 23.5°), Swivel Angle (+45° / -45°), Lift Range (155 mm), Pivot (-90° / 90°)

EU Energy Rating
C

Power Requirement
90 - 264 VAC, 50 - 60 Hz

Energy Star
8.0

Brand
ThinkVision

Included Accessory
HDMI cable, USB Type-A to Type-B cable

Color Coverage
72%NTSC

Color Depth
6 +FRC

Color Support
16.7 Million

Dimensions without Package
199.7 mm x 439.8 mm x 522 mm / 7.9" x 19.4" x 20.6"

Eye Caring
Yes

Head only Dimensions
46.4(D) x 313.1(H) x 522(W) mm / 1.8(D) x 12.3(H) x 20.6(W)"es

Height-Adjustable
Yes

Kensington Lock
Yes

Near Edgeless
3-side NearEdgeless

Power Consumption
15W/48W

Software/Driver
Yes (Thinkcolour)

TCO Edge
2.0

Weight Head Only
3.2 kg, 7.1 lbs

Weight with Package
7.3 kg, 16 lbs

Weight without Package
5.2 kg, 11.6 lbs

Maximum Resolution
1920 x 1080

Connection Type
1 x VGA, 1 x HDMI 1.4, 1 x DP 1.2, 4 x USB3.0, 1 x Audio out

Resolution
1920 x 1080

Refresh Rate
60 Hz

Manufacturer's Website:

www.lenovo.co.uk

Warranty:

Manufacturers Warranty - For further details please visit the manufacturers website.

DESIGN
Certification	ENERGY STAR® Certified, TCO 9.0, TCO Edge 2.0, EPEAT™ Gold, RoHS Eyesafe® Display, T�V Low Blue Light (Hardware solution), T�V Rheinland® Low Blue Light, T�V Rheinland® Flicker Free, T�V Rheinland® Eye Comfort
Product colour	Black
Detachable stand	Yes
Feet colour	Black
Front bezel colour	Black
Colour name	Raven Black
DISPLAY
Pixel pitch	0.265 x 0.265 mm
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Viewable size, horizontal	50.9 cm
Viewable size, vertical	28.6 cm
Display diagonal	58.4 cm (23")
Response time	6 ms
Colour depth	8 bit
Display resolution	1920 x 1080 pixels
Touchscreen	No
Contrast ratio (dynamic)	3000000:1
Backlight type	W-LED
Maximum refresh rate	60 Hz
Display technology	LED
Native aspect ratio	16:9
HD type	Full HD
Pixel density	96 ppi
Colour gamut	72%
Panel type	IPS
Screen shape	Flat
Display number of colours	16.7 million colours
Response time (fast)	4 ms
Display brightness (typical)	250 cd/m²
RGB colour space	NTSC
Colour gamut standard	NTSC
ENERGY MANAGEMENT
Power consumption (typical)	15 W
Power supply type	Internal
Power consumption (off)	0.5 W
Power consumption (standby)	0.5 W
AC input voltage	90 - 264 V
Power consumption (max)	48 W
ERGONOMICS
Cable lock slot	Yes
Height adjustment	Yes
Swivel angle range	-45 - 45°
Tilt angle range	-5 - 23.5°
Pivot	Yes
On Screen Display (OSD)	Yes
Cable management	Yes
Panel mounting interface	100 x 100 mm
Height adjustment	15.5 cm
Swivelling	Yes
Pivot angle	-90 - 90°
Cable lock slot type	Kensington
VESA mounting	Yes
MULTIMEDIA
Built-in speaker(s)	No
Built-in camera	No
OTHER FEATURES
Certification	ENERGY STAR® Certified, TCO 9.0, TCO Edge 2.0, EPEAT™ Gold, RoHS Eyesafe® Display, T�V Low Blue Light (Hardware solution), T�V Rheinland® Low Blue Light, T�V Rheinland® Flicker Free, T�V Rheinland® Eye Comfort
Compatible operating systems	Windows 10, Windows 11
Connection to PC	3.5 mm
Touchscreen	No
Power cable length	1.8 m
PACKAGING CONTENT
Cables included	AC, HDMI, USB
Quick start guide	Yes
Power cable length	1.8 m
Stand included	Yes
HDMI cable length	1.8 m
PACKAGING DATA
Package weight	7.3 kg
Cables included	AC, HDMI, USB
Package depth	150 mm
Package height	421 mm
Package width	592 mm
Quick start guide	Yes
Package type	Box
Stand included	Yes
HDMI cable length	1.8 m
PERFORMANCE
Compatible operating systems	Windows 10, Windows 11
NVIDIA G-SYNC	No
AMD FreeSync	No
Low Blue Light technology	Yes
PORTS & INTERFACES
Headphone outputs	1
VGA (D-Sub) ports quantity	1
HDMI ports quantity	1
Headphone connectivity	3.5 mm
HDMI version	1.4
HDMI	Yes
DisplayPorts quantity	1
DisplayPort version	1.2
Headphone out	Yes
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	4
Number of USB Type-B upstream ports quantity	1
WEIGHT & DIMENSIONS
Width (with stand)	522 mm
Height (with stand)	493.8 mm
Depth (with stand)	199.7 mm
Bezel width (side)	2 mm
Bezel width (top)	2 mm
Bezel width (bottom)	1.73 cm
Weight (without stand)	3.2 kg
Height (without stand)	313.1 mm
Width (without stand)	522 mm
Depth (without stand)	46.4 mm
Weight (with stand)	5.2 kg
