43" Outdoor Digital Android Battery A-Boards – 700CD/M²

Fully Portable
With a moulded polymer rear these displays are incredibly lightweight and this, along with their rugged castors, means they can easily be moved by one person. The specialised castors are designed to minimise vibrations on uneven surfaces, protecting the internal components for a longer product lifespan.

Tempered Anti-Glare Glass
These displays feature a tempered glass front that has been specially treated to give an anti-glare finish. This completely diffuses external light reflections without reducing the brightness of the screen, improving the readability of on-screen content.

Battery-Powered Display
The integrated lithium-polymer battery offers an amazing 27 hours run time from a single charge*, allowing you to display messaging all day and night without needing to recharge. A secure housing safely isolates this commercial grade battery from other components for total peace of mind.
*Based on average running time, subject to variation. Excludes degradation and user damage caused by sulphation, deep cycling, and overcharging.

Fully Weatherproof
Designed to withstand the elements, these displays are protected against all wet weather conditions and airborne dust particles by their robust IP65-rated outer casing. This means they can be used in any environment, come rain or shine.

700cd/m² High Brightness
These displays strike the perfect balance between brightness and battery life. With a high brightness panel which is up to three times brighter than a domestic TV, the screen is clearly visible in outdoor spaces without compromising on running time or battery lifespan.

Robust Fixed Design
Unlike traditional A-boards, these displays have a sturdy non- foldable design for ultimate durability and extended lifespan. This is further enhanced by the tempered glass front, which protects the panel and internal components from damage.

Secure Locking Bar
Once in position, the rugged castors can be locked in place with the built-in locking bar. For additional security, a padlock can be used to lock the bar in place.

Charge Level Indicator
The smart meter on the rear of the display tells you exactly how much charge the left battery has left, including an estimation of running time remaining, so you can rest assured that the battery will never die unexpectedly.

Integrated Android Media Player
The integrated Android media player allows you to easily update on-screen content via USB plug and play. Alternatively, upgrade your screen to be networked without needing any additional hardware to unlock our cloud-based CMS software. Third-party software can be installed instead if required.

Specifications

43 Inch - OAB43HD8-D
Display Area- 531.4x943.2
Unit Size - 1194.9x604.7x478
Package Size - 1310x745x645
Net Weight - 38.1kg
Gross Weight - 53.9kg
Footprint (WxH mm) - 604.7x478

Panel
Resolution - 1080x1920
Aspect Ratio - 16:9
Brightness (cd/m²) - 700
Colour - 16.7M
Contrast Ratio - 5,000:1
Viewing Angle -178°

Audio
Speaker Type - 5W, 8O (x2)

Battery
Battery Technology - Integrated lithium polymer
Charging Time - 7 hours
Battery Life - 27 hours*
Battery Capacity - 38000mA
Power Supply - 29.2V - 21.2V
Power Consumption - 73W

Environmental
Operating Temperature - -20°C to 70°C
Storage Temperature - -30°C to 60°C
Operating Humidity - 10% to 80%
Storage Humidity - 5% to 95%

Computer
Media Formats - Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)
Media Resolution - 1920x1080/1080x1920
CPU - Quad-Core ARM Cortex A17, 1.6GHz
GPU - Quad-Core ARM Mali-T764
RAM - DDR3 2GB
ROM - 8GB eMMC
USB - 1 x USB (OTG/HOST), 4 x USB (HOST)
Wi-Fi - 802.11b/g/n (Network version screen only)Android 7.1
Graphic Engine - OpenGL ES 1.1/2.0/3.0/3.1, OpenCL 1.1, Renderscript, Direct3D 11.1

Accessories
Included - Scheduling Software, Remote Control, User Manual, Charger, Mains Power Cable
Optional - Network Upgrade, Security Chain
