Target Components

Commercial Touch Screen Solution with Edge-to-Edge Glass and Integrated Android PC Android PCAP Touch Screens

Ultra Responsive Interactivity
Optimum sensitivity to touch gestures and rapid response times ensure that users have a smooth, effortless experience. There's no need to touch the same thing multiple times or wait for a touch to register when interacting with these ultra- responsive displays.

Protective Sleek Enclosure
These deluxe displays are the ultimate solution for interactivity in public spaces. As well as protecting the internal components, the robust aluminium surround and tempered edge-to-edge glass also deliver captivating tablet-like aesthetics for a truly high-end feel.

Toughened Safety Glass
Although the tempered glass face is incredibly tough, in the unlikely event of a breakage the specialised safety glass will shatter into small chunks rather than shards. Not only does this prevent injury, it also protects the LCD panel from damage.

10-Point PCAP Touch
Having up to 10 touch points allows users to perform a variety of touch gestures, including manipulating images and zooming in/out - much like you would with a domestic tablet or smart phone. It also allows multiple users to interact with the screen at the same time.

24/7 Commercial Use
These displays are able to be in constant use 24/7 for over 70,000 hours thanks to their commercial grade LCD panel, media player and other components. They also have no external buttons or controls to prevent tampering.
fingerprint

Surface Plasma Treatment
A special oleophobic coating makes the glass front more resistant to the oily residue left by fingerprints and improves the smoothness of touch gestures. Unlike other touch screens on the market, this glass is not etched, which vastly enhances the optical clarity.
ips panel

450cd/m² IPS Panel
Thanks to the commercial grade IPS technology, these panels are designed to accurately display image quality and colour depth with no fall-off in colour accuracy, as well as achieving ultimate lifelike colour temperature in both landscape and portrait orientations.

Lightweight Design
With a robust but lightweight aluminium enclosure and moulded polymer rear, these displays are over 30% lighter than their predecessor, allowing for easier installation and maintenance.

Touch Screen Monitor
Connect to an external source, such as a third-party PC or media player, using the built-in USB and HDMI or VGA/3.5mm audio inputs to use the display as touch screen monitor. This increases the versatility of applications that can be run

Free Wall Mount
A super slim wall mount is included at no extra cost, enabling you to install your screen in either landscape or portrait orientation with a secure and aesthetically-pleasing flush fit to the wall.

Touch Content Management SystemTouch Content Management System (CMS)
You can run your own touch software from the integrated PC board with Android or take advantage of our user friendly Touch Cloud Management System that puts you in control as you create, deploy and touch your very own content on screen. First, you create your custom layouts with our user friendly software that requires no knowledge of coding to use. Then deploy the content from your PC direct to your Touch Screens in a matter of seconds. Now all that is left to do is touch as you let your content do the talking about your brand, company, service or product.


Specifications

32 Inch - AO32H
Display Area- 697.4x391.3
Unit Size - 757.8x452.3x49.3
Package Size - 874x562x170
Net Weight - 12.05kg
Gross Weight - 14.9kg
VESA Holes - 400x200
Average Power Consumption (W) - 14.9

Panel
Resolution - 1080x1920
Aspect Ratio - 16:9
Brightness (cd/m²) - 450
Colour - 16.7M
Contrast Ratio - 5,000:1
Viewing Angle -178°

Touch
Touch Technology - Projected Capacitive
Touch Points - 10
Glass Hardness - 7H minimum

AV Inputs/Audio
Inputs (when used as monitor) - HDMI, VGA
Audio Input (when used as monitor) - Audio Socket (3.5mm)
Speaker Type - 2W, 5O (x2)

Power
Input Voltage - AC110~240V (50Hz~60Hz)

Environmental
Operating Temperature - 0°C to 50°C
Storage Temperature - -30°C to 60°C
Operating Humidity - 10% to 80%
Storage Humidity - 5% to 95%

Computer
CPU - Quad-Core ARM Cortex A17, 1.6GHz
GPU - Quad-Core ARM Mali-T764
RAM - DDR3 2GB
ROM - 8GB eMMC
USB - 1 x USB (OTG/HOST), 1 x USB (HOST)
LAN -10/100/1000 Ethernet
Wi-Fi - 802.11b/g/n
OS - Android 7.1
Graphic Engine - OpenGL ES 1.1/2.0/3.0/3.1, OpenCL 1.1, Renderscript, Direct3D 11.1

Accessories
Included - Wall Mount, Remote Control, User Manual, Power Cable, USB to USB Cable, Wi-Fi Aerial
Optional - Floor Stand/Trolley, Ceiling Mount, Table Stand
