Proven performance
Do more with less with the space-saving Lenovo ThinkCentre M70s Gen 4 (Intel) desktop PC. Its small chassis contains everything your enterprise needs, including up to Intel vPro Enterprise with 13th Gen Intel Core processors. You'll also get best-in-class connectivity, integrated AI accelerators, and extremely high memory capacity. Multitask with ease and efficiency as you seamlessly handle complex data operations and graphics projects.
Trusted security
Lenovo ThinkShield security offers a combination of hardware and software solutions to protect your ThinkCentre M70s PC. A discrete Trusted Platform Module (dTPM) 2.0 chip encrypts passwords and data. BIOS-based Smart USB protection and individual USB port disablement prevent unauthorized access. The Kensington Lock slots, chassis e-locks, and other options discourage physical theft. When paired with Intel vPro Enterprise, the M70s provides additional hardware-based security capabilities for next-level protection.
Expandable productivity
The ThinkCentre M70s desktop offers ample HDD and SDD expansion slots to grow along with your business. From industry-specific equipment to legacy peripherals, you can connect it all. Optional SSD storage offers fast access for boot-up, searches, and opening files, while 3D NAND technology gives the SSD more reliable performance and improved power consumption. This PC also provides time-saving and connectivity features like Smart Power On and Smart Cable, making your day that much easier.
Top-notch manageability & durability
With a variety of pre-installed OS options to meet your customization needs, the M70s is easy to deploy and manage — in terms of both software and hardware. The ease-of-use design offers quick access to the DIMM, HDD, SDD, and ODD for hassle-free expansion. And this PC meets MIL-STD 810H guidelines with 12 methods and 20 procedures — tested against real-world challenges like volt surges, shock, vibration, and extreme temperatures, it's ready for anything.
PERFORMANCE
Processor
Intel® Core™ i5-13400, 10C (6P + 4E) / 16T, P-core 2.5 / 4.6GHz, E-core 1.8 / 3.3GHz, 20MB
Graphics
Integrated Intel® UHD Graphics 730
Chipset
Intel® Q670 Chipset
Memory
1x 16GB UDIMM DDR4-3200
Memory Slots
Four DDR4 DIMM slots, dual-channel capable
Max Memory
Up to 128GB DDR4-3200
Storage
512GB SSD M.2 2280 PCIe® 4.0x4 Value NVMe® Opal 2.0
Storage Support
Up to three drives:
1x 2.5"/3.5" HDD + 1x 2.5" HDD + 1x M.2 SSD
2.5" HDD up to 1TB each
3.5" HDD up to 2TB
M.2 SSD up to 2TB
Card Reader
3-in-1 Card Reader
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC897Q-CG codec
Speakers
1Wx1
Power Supply
260W 90%
DESIGN
Keyboard
USB Traditional Keyboard, Black, English (UK)
Mouse
USB Calliope Mouse, Black
Optional Bay
None
Expansion Slots
One PCIe® 4.0 x16, low-profile, length = 155mm, height = 70mm
Two PCIe® 3.0 x1, low-profile, length = 155mm, height = 70mm
Two M.2 slots (one for WLAN, one for SSD)
Case Color
Black
Stand
None
Dust Filter
None
Pen
Pen Not Supported
Form Factor
SFF (8.2L)
Dimensions (WxDxH)
92.5 x 297.7 x 339.5 mm (3.6 x 11.7 x 13.4 inches)
Weight
Around 5.3 kg (11.7 lbs)
CONNECTIVITY
Ethernet
Integrated 100/1000M
WLAN + Bluetooth
None
WWAN
Non-WWAN
Front Ports
1x USB-C® 3.2 Gen 1 (15W charging)
2x USB 3.2 Gen 1
2x USB 3.2 Gen 2
1x headphone/microphone combo jack (3.5mm)
1x microphone (3.5mm)
Optional Front Ports (configured)
1x card reader
Rear Ports
4x USB 2.0
1x HDMI® 2.1 TMDS
2x DisplayPort™ 1.4a (HBR2, DSC)
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured)
None
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0, TCG certified
Fingerprint Reader
No fingerprint reader
Physical Locks
Kensington® Security Slot™, 3 x 7 mm
Padlock Loop
Smart Cable Clip
None
Chassis E-Lock
None
Chassis Intrusion Switch
None
MANAGEABILITY
System Management
Non-vPro®
SERVICE
Base Warranty
1-year, Onsite
Included Upgrade
3Y Onsite upgrade from 1Y Onsite, 1Y Premier Support TC DT/AIO Mainstream/Halo WHB (CPN), CO2 Offset 1 ton (2nd Generation Carbon Offset Projects)
CERTIFICATIONS
Green Certifications
ErP Lot 3
RoHS compliant
TCO Certified 9.0
Mil-Spec Test
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog)
SOFTWARE
Operating System
Windows® 11 Pro, English
