Tough. Ready. Scalable
Purpose-built for Connected-Home, SOHO
and Small-to-Medium Business NAS Environments
IronWolf™ is designed for consumer and commercial NAS. Delivering Tough, Ready and Scalable 24x7 performance in multibay, networked environments.
Optimised for NAS with AgileArray™ AgileArray enables Dual-Plane Balancing and Time-Limited Error Recovery to deliver best-in-class RAID performance in multi-bay systems.
Always On, Always Accessible
IronWolf drives are designed for 24x7 usage, allowing users to access their data any time, anywhere.
All-CMR Portfolio
All IronWolf drives utilize Conventional Magnetic Recording (CMR) technology for consistent, best-in-class NAS performance.
Up to 12 TB
Broad range of capacity options to deliver scalable and cost-efficient storage solutions.
Built Tough
IronWolf drives are rated for 180 TB/year workload, allowing consumer and commercial NAS users to seamlessly store and work with large amounts of networked data.
Superior Reliability and Dependability
IronWolf drives are rated for 1M hours MTBF and include a 3-year limited warranty for hassle-free data storage and best-in-class total cost of ownership (TCO)
Rotational Vibration (RV) sensors.
Built-in RV sensors for vibration tolerance and consistent performance in multi-bay systems.
IronWolf Health Management (IHM)
Actively protect your NAS data with Prevention, Intervention, and Recovery recommendations to ensure peak system health.
Peace of mind with Data Recovery
IronWolf drives include 3 years of complimentary Rescue Data Recovery Services - in-house secure facilities, with an industry-leading recovery rate of 95% - so you do not have to incur high recovery costs in the event of accidental data corruption or drive damage.
Model
ST2000VN003
Capacity
2TB
Interface
SATA III
Cache
256MB
Rotational Speed
5400RPM
Data Transfer
SATA III: 6.0 Gbit/s
Physical Drive Size
3.5"
Packaging
OEM anti-static bag
Warranty:
1 Year Return to Base, any additional warranty cover direct with Manufacturer. See www.seagate.com for details.
|
ENERGY MANAGEMENT
|
| Power consumption (typical) |
3.1 W |
| Power consumption (standby) |
0.25 W |
| Start-up current |
1.8 A |
| Operating voltage |
5 / 12 V |
| Power consumption (idle) |
2.8 W |
FEATURES
|
| HDD capacity |
2 TB |
| Interface |
Serial ATA III |
| Type |
HDD |
| HDD speed |
5400 RPM |
| Mean time between failures (MTBF) |
1000000 h |
| HDD size |
3.5" |
| Start/stop cycles |
600000 |
| Noise level (idle) |
21 dB |
| Component for |
NAS |
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^14 bits read |
| HDD interface transfer rate |
6 Gbit/s |
| Storage drive buffer size |
256 MB |
| Error Recovery Control (ERC) |
Yes |
| Rotational Vibration (RV) sensors |
Yes |
| 24/7 operation |
Yes |
OPERATIONAL CONDITIONS
|
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating temperature (T-T) |
0 - 65 °C |
| Operating shock |
80 G |
| Non-operating shock |
300 G |
WEIGHT & DIMENSIONS
|
| Weight |
415 g |
| Height |
20.2 mm |
| Width |
101.8 mm |
| Depth |
147 mm |
