Product Type | Liquid CPU Cooler |
Radiator Colour | Black |
Max Fan Speed | 1800RPM |
Radiator Size | 360mm |
LED Colour | ARGB |
DESIGN | |
---|---|
Material | Aluminium, Copper, EPDM |
Product colour | Black |
Number of fans | 3 fan(s) |
Water block material | Copper |
Fan connector | 4-pin |
Radiator material | Aluminum |
ENERGY MANAGEMENT | |
Pump voltage | 12 V |
Thermal Design Power (TDP) | 300 W |
Rated voltage | 12 V |
PACKAGING CONTENT | |
Cables included | SATA |
Manual | Yes |
Package type | Box |
Screws included | Yes |
PERFORMANCE | |
Type | Liquid cooling kit |
Mean time between failures (MTBF) | 30000 h |
Fan diameter | 12 cm |
Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), Socket AM2, Socket AM3, Socket AM4, Socket AM5, Socket FM1, Socket FM2 |
Suitable location | Processor |
Maximum airflow | 66.53 cfm |
Maximum air pressure | 1.86 mmH2O |
Pump motor speed (max) | 2750 RPM |
Pump motor speed (min) | 2250 RPM |
Rotational speed (max) | 1800 RPM |
Rotational speed (min) | 800 RPM |
Bearing type | Hydraulic |
Fan noise level (max) | 30 dB |
Pump noise level | 30 dB |
Pulse-width modulation (PWM) support | Yes |
TECHNICAL DETAILS | |
Warranty period | 2 year(s) |
WEIGHT & DIMENSIONS | |
Weight | 1.22 kg |
Package weight | 1.92 kg |
Package depth | 140 mm |
Package height | 467 mm |
Package width | 215 mm |
Radiator width | 39.5 cm |
Radiator depth | 12 cm |
Radiator height | 2.7 cm |
Tube length | 39 cm |
Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Waterblock width | 7.3 cm |
Waterblock depth | 8.3 cm |
Waterblock height | 5.3 cm |
Pump width | 7.3 cm |
Pump depth | 8.65 cm |
Pump height | 5.1 cm |
