Wattage | 1000W |
Size/Version | ATX 3.0 |
Modular | Fully |
SATA Connections | 12 |
Certification | Titanium |
Colour | Black |
CERTIFICATES | |
---|---|
Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
DESIGN | |
LED indicators | No |
Product colour | Black |
Illumination | No |
Number of fans | 1 fan(s) |
Cooling type | Active |
Fan diameter | 13.5 cm |
Fan location | Top |
Fan speed | 0 - 1800 RPM |
Built-in display | No |
ENERGY MANAGEMENT | |
Peak power | 1100 W |
Input current | 13/6 A |
Efficiency | 93.3% |
Hold time | 23.2 ms |
Power protection features | Over current, Over voltage, Overheating, Short circuit, Under voltage |
Power factor | 3 |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 125 W |
Combined power (+12V) | 996 W |
Combined power (+5V) | 125 W |
Combined power (-12V) | 6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 25 A |
Max output current (-12V) | 0.5 A |
Max output current (+5Vsb) | 3 A |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Max output current (+12V4) | 40 A |
Max output current (+12V3) | 40 A |
Max output current (+12V2) | 32 A |
Max output current (+12V1) | 32 A |
Total power | 1000 W |
Maximum input current (@110V) | 6 A |
Maximum input current (@220V) | 13 A |
LOGISTICS DATA | |
Shipping (inner) case width | 30.5 cm |
Shipping (inner) case length | 50.4 cm |
Shipping (inner) case height | 36.8 cm |
Pallet gross weight (air) | 19.3 kg |
PACKAGING CONTENT | |
Cables included | DC, SATA |
Cable tie(s) included | Yes |
PACKAGING DATA | |
Package weight | 4.48 kg |
Cables included | DC, SATA |
Package depth | 350 mm |
Package height | 270 mm |
Package width | 120 mm |
Package type | Box |
PERFORMANCE | |
Certification | BSMI, CB, CCC, CE, cTUVus, CU, FCC, RCM, T�V, UKCA, Triman |
ECC | Yes |
Noise level | 25.8 dB |
Purpose | PC |
Bearing technology | FDB |
Supported motherboard form factors | ATX |
ATX version | 3.0 |
EPS version | 2.92 |
80 PLUS certification | 80 PLUS Titanium |
Silent mode | Yes |
Power supply unit (PSU) form factor | ATX |
PORTS & INTERFACES | |
Floppy disk drive connector | No |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 13 |
Peripheral (Molex) power connectors (4-pin) | 1 |
ATX power connector (20+4 pin) | Yes |
CPU power connector (4+4 pin) | Yes |
CPU P4 connector (4-pin) | 1 |
PCI Express power connectors (6+2 pin) | 4 |
Cabling type | Modular |
Number of PATA power connectors | 3 |
Motherboard power cable length | 60 cm |
SATA power cable length | 1050 mm |
TECHNICAL DETAILS | |
Sustainability certificates | CCC, CE, ENERGY STAR, ErP, RoHS, WEEE |
Warranty period | 10 year(s) |
WEIGHT & DIMENSIONS | |
Weight | 2.03 kg |
Height | 175 mm |
Width | 150 mm |
Depth | 86 mm |
