Product Type | Fan Kit |
Fan Size | 120mm |
Max Fan Speed | 1700RPM |
Fan Shroud Colour | Black |
LED Colour | Addressable RGB |
Connections | 4-Pin Fan & 3-Pin ARGB |
DESIGN | |
---|---|
Product colour | Black |
Illumination colour | Multi |
Fan connector | 4-pin |
Illumination LED | Y |
ENERGY MANAGEMENT | |
Power consumption (typical) | 4.56 W |
Rated current | 0.07 A |
Maximum current | 0.38 A |
Voltage | 5 - 13.2 V |
Rated voltage | 12 V |
Safety current | 0.38 Ah |
LOGISTICS DATA | |
Shipping (inner) case width | 28.3 cm |
Shipping (inner) case length | 45.4 cm |
Shipping (inner) case height | 20 cm |
Shipping (inner) case gross weight | 8.91 kg |
Products per shipping (inner) case | 10 pc(s) |
Harmonized System (HS) code | 84733080 |
OTHER FEATURES | |
Country of origin | China |
Harmonized System (HS) code | 84733080 |
PACKAGING CONTENT | |
Number of screws | 16 |
Screws included | Y |
Hub included | Y |
PERFORMANCE | |
Type | Fan |
Mean time between failures (MTBF) | 60000 h |
Compatible processor series | Not supported |
Airflow | 70.53 m�/h |
Fan diameter | 12 cm |
Supported processor sockets | Not supported |
Suitable location | Computer case |
Maximum airflow | 41.51 cfm |
Maximum air pressure | 1.66 mmH2O |
Noise level (high speed) | 20.6 dB |
Rotational speed (max) | 1700 RPM |
Bearing type | Rifle bearing |
Quantity per pack | 3 pc(s) |
Pulse-width modulation (PWM) support | Y |
TECHNICAL DETAILS | |
Sustainability compliance | Y |
Sustainability certificates | CE, RoHS, WEEE |
WEIGHT & DIMENSIONS | |
Weight | 200 g |
Package weight | 833 g |
Cable length | 0.5 m |
Package depth | 172 mm |
Package height | 29.5 mm |
Package width | 133 mm |
Fan weight | 200 g |
Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
